一、Yao 完整 Dockerfile（生产可直接构建）

FROM debian:12-slim

# 基础依赖
RUN apt update && apt install -y --no-install-recommends ca-certificates curl openssl tzdata && \
    rm -rf /var/lib/apt/lists/*

ENV TZ=Asia/Shanghai
WORKDIR /app

# 拉取 Yao 稳定二进制
RUN curl -fsSL https://github.com/YaoApp/yao/releases/latest/download/yao-linux-amd64 -o /app/yao && \
    chmod +x /app/yao

# 数据持久化目录
VOLUME ["/app/data", "/app/models", "/app/scripts", "/app/public"]

# 内网服务端口
EXPOSE 8080 8081

# 启动命令
CMD ["/app/yao", "start", "--host", "0.0.0.0", "--port", "8080"]

二、K8s 全套部署 YAML（ns-cmdb 命名空间）

1. namespace.yaml

apiVersion: v1
kind: Namespace
metadata:
  name: ns-cmdb
  labels:
    biz: cmdb
    env: prod

2. ConfigMap：Yao 全局配置 configmap-yao.yaml

apiVersion: v1
kind: ConfigMap
metadata:
  name: yao-config
  namespace: ns-cmdb
data:
  .env: |
    # 内网域名
    YAO_APP_NAME=IDC资产管控平台
    YAO_HOST=0.0.0.0
    YAO_PORT=8080
    # 内网DNS
    DNS_SERVER=10.0.30.10
    # K8s APIServer 地址（堡垒机代理访问）
    K8S_API=https://10.0.40.9:6443
    # 堡垒机集群VIP
    BASTION_URL=https://10.0.30.5:443
    BASTION_SSH=10.0.30.5:2222
    # ELK日志地址
    ELK_LOG=http://log.internal.local:9200
    # LDAP统一账号
    LDAP_ADDR=ldap://10.0.30.10:389
  k8s-api.ts: |
    export async function GetK8sToken() {
      return Process.env.K8S_BEARER_TOKEN
    }
    export async function ListAllNode() {
      const token = await GetK8sToken()
      const resp = await Fetch(Process.env.K8S_API + "/api/v1/nodes", {
        headers: {
          "Authorization": `Bearer ${token}`,
          "Content-Type": "application/json"
        },
        timeout: 10000
      })
      return resp.items
    }

3. Secret：存储敏感密钥 secret-yao.yaml

apiVersion: v1
kind: Secret
metadata:
  name: yao-secret
  namespace: ns-cmdb
type: Opaque
data:
  # K8s ServiceAccount Token base64
  K8S_BEARER_TOKEN: c2FtLXJlbXBsYWNlLXRva2Vu
  # 堡垒机API密钥
  BASTION_API_KEY: YmFzdGlvbjE5OTkwNjIw
  # MFA加密密钥
  MFA_SECRET: eWFvY21kYl9zZWN1cmU=

4. StorageClass 持久化 PVC pvc-yao.yaml

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: yao-data-pvc
  namespace: ns-cmdb
spec:
  storageClassName: cephfs-prod
  accessModes:
    - ReadWriteMany
  resources:
    requests:
      storage: 20Gi

5. Deployment 主应用 deployment-yao.yaml

apiVersion: apps/v1
kind: Deployment
metadata:
  name: yao-cmdb
  namespace: ns-cmdb
  labels:
    app: yao
spec:
  replicas: 2
  selector:
    matchLabels:
      app: yao
  strategy:
    rollingUpdate:
      maxSurge: 1
      maxUnavailable: 0
  template:
    metadata:
      labels:
        app: yao
    spec:
      securityContext:
        runAsUser: 1000
        fsGroup: 1000
      containers:
      - name: yao
        image: yao-cmdb:v0.10.2
        imagePullPolicy: IfNotPresent
        envFrom:
        - configMapRef:
            name: yao-config
        - secretRef:
            name: yao-secret
        volumeMounts:
        - name: data-storage
          mountPath: /app/data
        - name: script-config
          mountPath: /app/scripts
          subPath: k8s-api.ts
        ports:
        - containerPort: 8080
          name: web
        - containerPort: 8081
          name: api
        resources:
          requests:
            cpu: 500m
            memory: 1Gi
          limits:
            cpu: 1500m
            memory: 2Gi
        livenessProbe:
          httpGet:
            path: /ping
            port: web
          initialDelaySeconds: 30
          periodSeconds: 10
        readinessProbe:
          httpGet:
            path: /ready
            port: web
          initialDelaySeconds: 10
          periodSeconds: 5
      volumes:
      - name: data-storage
        persistentVolumeClaim:
          claimName: yao-data-pvc
      - name: script-config
        configMap:
          name: yao-config
          items:
          - key: k8s-api.ts
            path: k8s-api.ts

6. Service service-yao.yaml

apiVersion: v1
kind: Service
metadata:
  name: yao-svc
  namespace: ns-cmdb
spec:
  selector:
    app: yao
  ports:
  - port: 80
    targetPort: web
    name: http
  - port: 8081
    targetPort: api
    name: api
  type: ClusterIP

7. 内网Ingress ingress-yao.yaml（仅内网解析）

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: yao-ingress
  namespace: ns-cmdb
  annotations:
    kubernetes.io/ingress.class: internal-nginx
    nginx.ingress.kubernetes.io/ssl-redirect: "true"
    nginx.ingress.kubernetes.io/whitelist-source-range: "10.0.30.0/24,办公专线网段"
spec:
  tls:
  - hosts:
    - yao.cmdb.internal.local
    secretName: internal-tls-cert
  rules:
  - host: yao.cmdb.internal.local
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: yao-svc
            port:
              name: http

三、堡垒机资产同步完整 TS 脚本 scripts/bastion-sync.ts

// 同步堡垒机服务器资产、账号、审计日志到Yao CMDB
export async function SyncBastionAsset() {
  const apiHost = Process.env.BASTION_URL
  const apiKey = Process.env.BASTION_API_KEY
  const headers = {
    "Authorization": `Bearer ${apiKey}`,
    "Content-Type": "application/json"
  }

  // 1. 同步主机资产列表
  const assetResp = await Fetch(`${apiHost}/api/v1/assets`, { headers })
  const assets = assetResp.data

  // 批量写入CMDB Asset表
  for (const item of assets) {
    await DB.Save("asset", {
      asset_type: item.category,
      ip_addr: item.ip,
      vlan_id: item.vlan,
      zone: item.idc_zone,
      admin_user: item.owner,
      hostname: item.hostname
    })
  }

  // 2. 同步审计操作日志
  const logResp = await Fetch(`${apiHost}/api/v1/audit/logs?limit=1000`, { headers })
  const logs = logResp.data
  for (const log of logs) {
    await DB.Save("audit_log", {
      asset_id: log.asset_id,
      operator: log.username,
      cmd: log.command,
      login_ip: log.source_ip,
      operate_time: log.operate_at,
      risk_level: log.risk
    })
  }

  return {
    sync_asset_count: assets.length,
    sync_log_count: logs.length,
    update_at: new Date()
  }
}

// 定时同步入口，配置Yao定时任务每30分钟执行
export async function CronSyncTask() {
  return await SyncBastionAsset()
}

四、部署执行顺序

1. kubectl apply -f namespace.yaml
2. kubectl apply -f configmap-yao.yaml
3. kubectl apply -f secret-yao.yaml
4. kubectl apply -f pvc-yao.yaml
5. kubectl apply -f deployment-yao.yaml
6. kubectl apply -f service-yao.yaml
7. kubectl apply -f ingress-yao.yaml

五、配套 Yao 资产模型 model/asset.mod.yao

{
  "name": "Asset",
  "label": "IDC资产台账",
  "columns": [
    {"name":"hostname","type":"string","label":"主机名"},
    {"name":"asset_type","type":"enum","option":["server","k8s_node","firewall","bastion","storage","mysql","redis"],"label":"资产类型"},
    {"name":"ip_addr","type":"string","label":"内网IP"},
    {"name":"vlan_id","type":"integer","label":"VLAN"},
    {"name":"zone","type":"string","label":"机房区域"},
    {"name":"admin_user","type":"string","label":"负责人"},
    {"name":"expire_time","type":"datetime","label":"租期到期时间"}
  ],
  "relations": {
    "audit_logs": {"type":"hasMany","model":"AuditLog","foreign":"asset_id"}
  },
  "option": {
    "timestamps": true
  }
}
