万能链接脚本

链接脚本中定义了入口函数，也即上电之后执行的第一个函数 Reset_Handler、定义了内存区域分配情况，以及手动去除一些标准库中的信息。

ST 官方并未在标准外设库中提供适用于各种型号的链接脚本，只有在项目实例中给出了零星几个型号项目的链接脚本。但是在 HAL 库中提供了如下链接脚本可供参考：

• STM32F100XB_FLASH.ld
• STM32F100XE_FLASH.ld
• STM32F101X6_FLASH.ld
• STM32F101XB_FLASH.ld
• STM32F101XE_FLASH.ld
• STM32F101XG_FLASH.ld
• STM32F102X6_FLASH.ld
• STM32F102XB_FLASH.ld
• STM32F103X6_FLASH.ld
• STM32F103XB_FLASH.ld
• STM32F103XE_FLASH.ld
• STM32F103XG_FLASH.ld
• STM32F105XC_FLASH.ld
• STM32F107XC_FLASH.ld

上述文件可以在 ST 官方提供的 STM32F1 系列 HAL 库中找到，路径为：STM32Cube_FW_F1_V1.8.7/Drivers/CMSIS/Device/ST/STM32F1xx/Source/Templates/gcc/linker/

阅读上述链接脚本会发现，他们之间几乎完全相同，唯一的区别就是栈顶指针和 RAM、FLASH 区域的大小：

	/* STM32F101X6_FLASH.ld */
	/* Highest address of the user mode stack */
	_estack = 0x200017FF; /* end of RAM */
	/* Generate a link error if heap and stack don't fit into RAM */
	_Min_Heap_Size = 0x200; /* required amount of heap */
	_Min_Stack_Size = 0x400; /* required amount of stack */
	/* Specify the memory areas */
	MEMORY
	{
	FLASH (rx) : ORIGIN = 0x08000000, LENGTH = 32K
	RAM (xrw) : ORIGIN = 0x20000000, LENGTH = 6K
	}
	/* STM32F103XB_FLASH.ld */
	/* Highest address of the user mode stack */
	_estack = 0x20004FFF; /* end of RAM */
	/* Generate a link error if heap and stack don't fit into RAM */
	_Min_Heap_Size = 0x200; /* required amount of heap */
	_Min_Stack_Size = 0x400; /* required amount of stack */
	/* Specify the memory areas */
	MEMORY
	{
	FLASH (rx) : ORIGIN = 0x08000000, LENGTH = 128K
	RAM (xrw) : ORIGIN = 0x20000000, LENGTH = 20K
	}

对此，我们希望实现一份“万能链接脚本”，实现之后可以无缝衔接到任何项目中而无需修改源代码，需要变更的参数通过项目配置来实现。对此，可以使用 GNU Linker Script 中的 PROVIDE 指令来实现。PROVIDE 指令可以为脚本内的变量提供默认值，同时也支持通过传入链接器参数 -Wl,--defsym=symbol=value 来覆盖默认值。借此，可以将 RAM、FLASH 大小设置为可以被覆盖的值。此外用户堆栈大小 _Min_Stack_Size 和 _Min_Heap_Size 也可以根据实际情况调整：

	PROVIDE(_Ram_Size = 10K); /* RAM size, 默认 : 10K */
	PROVIDE(_Flash_Size = 32K); /* FLASH size, 默认 : 32K */
	PROVIDE(_Min_Heap_Size = 0); /* 堆大小, 默认 : 0 */
	PROVIDE(_Min_Stack_Size = 1K); /* 栈大小, 默认 : 1K */
	MEMORY
	{
	FLASH (rx) : ORIGIN = 0x08000000, LENGTH = _Flash_Size
	RAM (rwx) : ORIGIN = 0x20000000, LENGTH = _Ram_Size
	}

栈顶指针 _estack 应当始终为 RAM 空间的结束为止，因为栈指针是从高地址向低地址增长的。将其定义在 MEMORY 区域之后，利用表达式动态计算其值，避免硬编码：

_estack = ORIGIN(RAM) + _Ram_Size;

其余部分复制粘贴即可，不用修改。

使用例

将上述万能链接脚本作为某项目的链接脚本，默认 10K RAM/32K FLASH 是 STM32F103C6T6 的容量，添加链接器参数 -Wl,--defsym=_Ram_Size=20K -Wl,--defsym=_Flash_Size=64K ，就可以适配 20K RAM/64K FLASH 的 STM32F103C8T6 了。

万能启动文件

启动文件中使用 ARM 汇编做了三件事：实现函数 Reset_Handler、定义中断向量表，以及为各个中断函数提供默认实现和弱符号定义。

ST 官方为 STM32F10X 系列 MCU 提供了如下启动文件：

• startup_stm32f10x_cl.s
• startup_stm32f10x_hd.s
• startup_stm32f10x_hd_vl.s
• startup_stm32f10x_ld.s
• startup_stm32f10x_ld_vl.s
• startup_stm32f10x_md.s
• startup_stm32f10x_md_vl.s
• startup_stm32f10x_xl.s

上述文件可以在 ST 官方提供的 STM32F10X 系列标准外设库中找到，路径为 STM32F10x_StdPeriph_Lib_V3.6.0/Libraries/CMSIS/CM3/DeviceSupport/ST/STM32F10x/startup/TrueSTUDIO/

其命名规则为，常见的 F101、102、103 分为低容量（Low Density）、中容量（Medium Density）、高容量（High Density）三种，分别使用 ld、md、hd 后缀。

• F100 属于超值系列（Value Line），因此其启动文件有 vl 后缀，再根据容量不同，就有了 ld_vl、md_vl 和 hd_vl。
• F105/107 属于互联型（Connectivity Line），因此后缀为 cl。
• xl 代表超大容量产品，包括 F101 和 F103 的 ZF、ZG 版本，容量分别为 768K/80K 和 1M/80K。

阅读各个版本的启动文件可以发现，各种启动文件几乎完全相同，唯一区别就是 BootRAM 的值、中断向量表的大小以及中断函数名称不同。因此很容易就能想到使用 C 语言的条件编译功能，可以实现一份“万能启动文件”。

首先根据不同型号的宏定义，定义不同的 BootRAM 值：

	/* Specific value for RAM boot mode */
	#if defined(STM32F10X_LD)
	#define BootRAM 0xF108F85F
	#elif defined(STM32F10X_LD_VL)
	#define BootRAM 0xF108F85F
	#elif defined(STM32F10X_MD)
	#define BootRAM 0xF108F85F
	#elif defined(STM32F10X_MD_VL)
	#define BootRAM 0xF108F85F
	#elif defined(STM32F10X_HD)
	#define BootRAM 0xF1E0F85F
	#elif defined(STM32F10X_HD_VL)
	#define BootRAM 0xF108F85F
	#elif defined(STM32F10X_XL)
	#define BootRAM 0xF1E0F85F
	#elif defined(STM32F10X_CL)
	#define BootRAM 0xF1E0F85F
	#endif

然后是中断函数的声明：

	// 这一部分是通用的中断函数，适用于任何型号，因此不用放在条件编译中
	/* System exception handlers */
	__attribute__((weak, alias("Default_Handler"))) void NMI_Handler(void);
	__attribute__((weak, alias("Default_Handler"))) void HardFault_Handler(void);
	__attribute__((weak, alias("Default_Handler"))) void MemManage_Handler(void);
	__attribute__((weak, alias("Default_Handler"))) void BusFault_Handler(void);
	__attribute__((weak, alias("Default_Handler"))) void UsageFault_Handler(void);
	__attribute__((weak, alias("Default_Handler"))) void SVC_Handler(void);
	__attribute__((weak, alias("Default_Handler"))) void DebugMon_Handler(void);
	__attribute__((weak, alias("Default_Handler"))) void PendSV_Handler(void);
	__attribute__((weak, alias("Default_Handler"))) void SysTick_Handler(void);
	// 这一部分是外设中断，根据型号不同有不同的名称
	/* Peripheral interrupt handlers */
	#if defined(STM32F10X_LD)
	// ...
	#elif defined(STM32F10X_LD_VL)
	#elif defined(STM32F10X_MD)
	#elif defined(STM32F10X_MD_VL)
	#elif defined(STM32F10X_HD)
	#elif defined(STM32F10X_HD_VL)
	#elif defined(STM32F10X_XL)
	#elif defined(STM32F10X_CL)
	#endif

最后是中断向量表的定义：

	/* Interrupt handler function pointer type definition */
	typedef void (*InterruptHandlerPtr_TypeDef)(void);
	/* The Vector Table */
	__attribute__((used, section(".isr_vector")))
	InterruptHandlerPtr_TypeDef g_pfnVectors[] = {
	/* Initial stack pointer */
	(InterruptHandlerPtr_TypeDef)(uintptr_t)_estack,
	/* Core exceptions */
	#if defined(STM32F10X_LD)
	// ...
	#elif defined(STM32F10X_LD_VL)
	#elif defined(STM32F10X_MD)
	#elif defined(STM32F10X_MD_VL)
	#elif defined(STM32F10X_HD)
	#elif defined(STM32F10X_HD_VL)
	#elif defined(STM32F10X_XL)
	#elif defined(STM32F10X_CL)
	#endif
	(InterruptHandlerPtr_TypeDef)BootRAM,
	};

最后根据不同的启动文件中的函数不同填充上述条件编译框架，就得到了一份“万能启动文件”，适用于 STM32F10X 所有系列的 MCU。

附录

链接脚本

	/* STM32F10X 链接脚本 */
	/* 程序入口 */
	ENTRY(Reset_Handler)
	/* 指定内存区域 */
	/* 可以使用连接器参数 -Wl,--defsym=_foo=_size 来设置 RAM 和 FLASH 大小 */
	PROVIDE(_Ram_Size = 10K); /* RAM size, 默认 : 10K */
	PROVIDE(_Flash_Size = 32K); /* FLASH size, 默认 : 32K */
	/* 用户堆栈大小 */
	PROVIDE(_Min_Heap_Size = 0); /* 堆大小, 默认 : 0 */
	PROVIDE(_Min_Stack_Size = 1K); /* 栈大小, 默认 : 1K */
	/* 内存区域定义 */
	MEMORY
	{
	FLASH (rx) : ORIGIN = 0x08000000, LENGTH = _Flash_Size
	RAM (rwx) : ORIGIN = 0x20000000, LENGTH = _Ram_Size
	}
	/* 栈顶指针 */
	_estack = ORIGIN(RAM) + _Ram_Size;
	/* 定义段 */
	SECTIONS
	{
	/* 向量表位于 FLASH 区域起始位置 */
	.isr_vector :
	{
	. = ALIGN(4); /* 起始位置 4 字节对齐 */
	KEEP(*(.isr_vector)) /* 始终保留 */
	. = ALIGN(4); /* 结束位置 4 字节对齐 */
	} >FLASH /* 存放到 FLASH 区域 */
	/* 程序代码保存到 FLASH 中 */
	.text :
	{
	. = ALIGN(4);
	*(.text*) /* 代码段 .text* */
	*(.glue_7)
	*(.glue_7t) /* arm 和 thumb 胶水代码 */
	*(.eh_frame) /* 异常处理框架 */
	KEEP(*(.init))
	KEEP(*(.fini))
	. = ALIGN(4);
	_etext = .; /* 定义程序段结束地址 */
	} >FLASH
	/* 常量数据保存到 FLASH 中 */
	.rodata :
	{
	. = ALIGN(4);
	*(.rodata*) /* 只读数据段 .rodata* 如 cosnt 变量、字符串常量 */
	. = ALIGN(4);
	} >FLASH
	/* ARM 异常处理相关段 */
	.ARM.extab :
	{
	*(.ARM.extab* .gnu.linkonce.armextab.*)
	} >FLASH
	.ARM :
	{
	__exidx_start = .;
	*(.ARM.exidx*)
	__exidx_end = .;
	} >FLASH
	.ARM.attributes :
	{
	*(.ARM.attributes)
	} >FLASH
	.preinit_array :
	{
	PROVIDE_HIDDEN(__preinit_array_start = .);
	KEEP(*(.preinit_array*))
	PROVIDE_HIDDEN(__preinit_array_end = .);
	} >FLASH
	.init_array :
	{
	PROVIDE_HIDDEN (__init_array_start = .);
	KEEP(*(SORT(.init_array.*)))
	KEEP(*(.init_array*))
	PROVIDE_HIDDEN (__init_array_end = .);
	} >FLASH
	.fini_array :
	{
	PROVIDE_HIDDEN (__fini_array_start = .);
	KEEP(*(.fini_array*))
	KEEP(*(SORT(.fini_array.*)))
	PROVIDE_HIDDEN (__fini_array_end = .);
	} >FLASH
	/* 导出符号，用于启动文件中初始化数据 */
	_sidata = LOADADDR(.data);
	/* 已初始化的数据段在运行时复制到 RAM 中 */
	.data :
	{
	. = ALIGN(4);
	_sdata = .; /* 定义 .data 段起始地址 */
	*(.data*) /* .data 数据段 */
	. = ALIGN(4);
	_edata = .; /* 定义 .data 段结束地址 */
	} >RAM AT>FLASH
	/* 未初始化的数据段 */
	.bss :
	{
	. = ALIGN(4);
	_sbss = .; /* 定义 .bss 段起始地址 */
	__bss_start__ = _sbss;
	*(.bss*) /* .bss 段 */
	*(COMMON)
	. = ALIGN(4);
	_ebss = .; /* 定义 .bss 段结束地址 */
	__bss_end__ = _ebss;
	} >RAM
	/* 用户堆栈段 */
	._user_heap_stack :
	{
	. = ALIGN(8);
	PROVIDE(end = .); /* 定义 end 符号 */
	PROVIDE(_end = .); /* 定义 _end 符号 */
	. = . + _Min_Heap_Size; /* 添加用户堆大小 */
	. = . + _Min_Stack_Size; /* 添加用户栈大小 */
	. = ALIGN(8);
	} >RAM
	/* 移除 C 标准库 */
	/DISCARD/ :
	{
	libc.a ( * )
	libm.a ( * )
	libgcc.a ( * )
	}
	}

启动文件

	#include <stddef.h>
	#include <stdint.h>
	/* Symbols Defined in Linker Script */
	extern uint8_t _estack[]; /* Top of Stack Pointer */
	extern uint8_t _sidata[]; /* Start address for .data initialization values (in Flash) */
	extern uint8_t _sdata[]; /* Start address for .data section (in RAM) */
	extern uint8_t _edata[]; /* End address for .data section (in RAM) */
	extern uint8_t _sbss[]; /* Start address for .bss section (in RAM) */
	extern uint8_t _ebss[]; /* End address for .bss section (in RAM) */
	/* Specific value for RAM boot mode */
	#if defined(STM32F10X_LD)
	#define BootRAM 0xF108F85F
	#elif defined(STM32F10X_LD_VL)
	#define BootRAM 0xF108F85F
	#elif defined(STM32F10X_MD)
	#define BootRAM 0xF108F85F
	#elif defined(STM32F10X_MD_VL)
	#define BootRAM 0xF108F85F
	#elif defined(STM32F10X_HD)
	#define BootRAM 0xF1E0F85F
	#elif defined(STM32F10X_HD_VL)
	#define BootRAM 0xF108F85F
	#elif defined(STM32F10X_XL)
	#define BootRAM 0xF1E0F85F
	#elif defined(STM32F10X_CL)
	#define BootRAM 0xF1E0F85F
	#elif
	#error "Invalid device selected."
	#endif
	/* External function declarations */
	extern void SystemInit(void); /* Defined in system_stm32f10x.c */
	extern int main(void); /* Defined in main.c */
	extern void __libc_init_array(void); /* Newlib library initialization */
	/* Function prototypes */
	void Default_Handler(void);
	__attribute__((weak)) void Reset_Handler(void);
	/* Provide weak aliases for each Exception handler to the Default_Handler */
	/* System exception handlers */
	__attribute__((weak, alias("Default_Handler"))) void NMI_Handler(void);
	__attribute__((weak, alias("Default_Handler"))) void HardFault_Handler(void);
	__attribute__((weak, alias("Default_Handler"))) void MemManage_Handler(void);
	__attribute__((weak, alias("Default_Handler"))) void BusFault_Handler(void);
	__attribute__((weak, alias("Default_Handler"))) void UsageFault_Handler(void);
	__attribute__((weak, alias("Default_Handler"))) void SVC_Handler(void);
	__attribute__((weak, alias("Default_Handler"))) void DebugMon_Handler(void);
	__attribute__((weak, alias("Default_Handler"))) void PendSV_Handler(void);
	__attribute__((weak, alias("Default_Handler"))) void SysTick_Handler(void);
	/* Peripheral interrupt handlers */
	#if defined(STM32F10X_LD)
	__attribute__((weak, alias("Default_Handler"))) void WWDG_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void PVD_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TAMPER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RTC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void FLASH_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RCC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI0_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel6_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel7_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void ADC1_2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USB_HP_CAN1_TX_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USB_LP_CAN1_RX0_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CAN1_RX1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CAN1_SCE_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI9_5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_BRK_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_UP_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_TRG_COM_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_CC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM3_IRQHandler(void);
	/* Reversed */
	__attribute__((weak, alias("Default_Handler"))) void I2C1_EV_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C1_ER_IRQHandler(void);
	/* Reversed */
	/* Reversed */
	__attribute__((weak, alias("Default_Handler"))) void SPI1_IRQHandler(void);
	/* Reversed */
	__attribute__((weak, alias("Default_Handler"))) void USART1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART2_IRQHandler(void);
	/* Reversed */
	__attribute__((weak, alias("Default_Handler"))) void EXTI15_10_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RTCAlarm_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USBWakeUp_IRQHandler(void);
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* BootRAM */
	#elif defined(STM32F10X_LD_VL)
	__attribute__((weak, alias("Default_Handler"))) void WWDG_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void PVD_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TAMPER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RTC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void FLASH_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RCC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI0_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel6_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel7_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void ADC1_IRQHandler(void);
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	__attribute__((weak, alias("Default_Handler"))) void EXTI9_5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_BRK_TIM15_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_UP_TIM16_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_TRG_COM_TIM17_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_CC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM3_IRQHandler(void);
	/* Reversed */
	__attribute__((weak, alias("Default_Handler"))) void I2C1_EV_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C1_ER_IRQHandler(void);
	/* Reversed */
	/* Reversed */
	__attribute__((weak, alias("Default_Handler"))) void SPI1_IRQHandler(void);
	/* Reversed */
	__attribute__((weak, alias("Default_Handler"))) void USART1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART2_IRQHandler(void);
	/* Reversed */
	__attribute__((weak, alias("Default_Handler"))) void EXTI15_10_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RTCAlarm_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CEC_IRQHandler(void);
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	__attribute__((weak, alias("Default_Handler"))) void TIM6_DAC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM7_IRQHandler(void);
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* BootRAM */
	#elif defined(STM32F10X_MD)
	__attribute__((weak, alias("Default_Handler"))) void WWDG_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void PVD_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TAMPER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RTC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void FLASH_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RCC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI0_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel6_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel7_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void ADC1_2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USB_HP_CAN1_TX_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USB_LP_CAN1_RX0_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CAN1_RX1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CAN1_SCE_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI9_5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_BRK_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_UP_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_TRG_COM_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_CC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C1_EV_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C1_ER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C2_EV_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C2_ER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SPI1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SPI2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI15_10_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RTCAlarm_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USBWakeUp_IRQHandler(void);
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* BootRAM */
	#elif defined(STM32F10X_MD_VL)
	__attribute__((weak, alias("Default_Handler"))) void WWDG_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void PVD_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TAMPER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RTC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void FLASH_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RCC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI0_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel6_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel7_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void ADC1_IRQHandler(void);
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	__attribute__((weak, alias("Default_Handler"))) void EXTI9_5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_BRK_TIM15_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_UP_TIM16_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_TRG_COM_TIM17_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_CC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C1_EV_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C1_ER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C2_EV_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C2_ER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SPI1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SPI2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI15_10_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RTCAlarm_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CEC_IRQHandler(void);
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	__attribute__((weak, alias("Default_Handler"))) void TIM6_DAC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM7_IRQHandler(void);
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	#elif defined(STM32F10X_HD)
	__attribute__((weak, alias("Default_Handler"))) void WWDG_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void PVD_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TAMPER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RTC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void FLASH_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RCC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI0_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel6_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel7_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void ADC1_2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USB_HP_CAN1_TX_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USB_LP_CAN1_RX0_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CAN1_RX1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CAN1_SCE_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI9_5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_BRK_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_UP_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_TRG_COM_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_CC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C1_EV_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C1_ER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C2_EV_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C2_ER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SPI1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SPI2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI15_10_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RTCAlarm_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USBWakeUp_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM8_BRK_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM8_UP_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM8_TRG_COM_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM8_CC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void ADC3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void FSMC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SDIO_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SPI3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void UART4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void UART5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM6_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM7_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel4_5_IRQHandler(void);
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* BootRAM */
	#elif defined(STM32F10X_HD_VL)
	__attribute__((weak, alias("Default_Handler"))) void WWDG_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void PVD_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TAMPER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RTC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void FLASH_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RCC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI0_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel6_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel7_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void ADC1_IRQHandler(void);
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	__attribute__((weak, alias("Default_Handler"))) void EXTI9_5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_BRK_TIM15_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_UP_TIM16_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_TRG_COM_TIM17_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_CC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C1_EV_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C1_ER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C2_EV_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C2_ER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SPI1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SPI2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI15_10_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RTCAlarm_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CEC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM12_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM13_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM14_IRQHandler(void);
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	__attribute__((weak, alias("Default_Handler"))) void TIM5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SPI3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void UART4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void UART5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM6_DAC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM7_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel4_5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel5_IRQHandler(void);
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* BootRAM */
	#elif defined(STM32F10X_XL)
	__attribute__((weak, alias("Default_Handler"))) void WWDG_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void PVD_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TAMPER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RTC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void FLASH_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RCC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI0_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel6_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel7_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void ADC1_2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USB_HP_CAN1_TX_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USB_LP_CAN1_RX0_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CAN1_RX1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CAN1_SCE_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI9_5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_BRK_TIM9_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_UP_TIM10_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_TRG_COM_TIM11_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_CC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C1_EV_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C1_ER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C2_EV_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C2_ER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SPI1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SPI2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI15_10_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RTCAlarm_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USBWakeUp_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM8_BRK_TIM12_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM8_UP_TIM13_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM8_TRG_COM_TIM14_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM8_CC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void ADC3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void FSMC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SDIO_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SPI3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void UART4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void UART5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM6_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM7_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel4_5_IRQHandler(void);
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* BootRAM */
	#elif defined(STM32F10X_CL)
	__attribute__((weak, alias("Default_Handler"))) void WWDG_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void PVD_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TAMPER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RTC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void FLASH_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RCC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI0_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel6_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA1_Channel7_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void ADC1_2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CAN1_TX_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CAN1_RX0_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CAN1_RX1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CAN1_SCE_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI9_5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_BRK_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_UP_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_TRG_COM_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM1_CC_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C1_EV_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C1_ER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C2_EV_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void I2C2_ER_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SPI1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SPI2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void USART3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void EXTI15_10_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void RTCAlarm_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void OTG_FS_WKUP_IRQHandler(void);
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	__attribute__((weak, alias("Default_Handler"))) void TIM5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void SPI3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void UART4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void UART5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM6_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void TIM7_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel2_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel3_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel4_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void DMA2_Channel5_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void ETH_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void ETH_WKUP_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CAN2_TX_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CAN2_RX0_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CAN2_RX1_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void CAN2_SCE_IRQHandler(void);
	__attribute__((weak, alias("Default_Handler"))) void OTG_FS_IRQHandler(void);
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* Reversed */
	/* BootRAM */
	#endif
	/* Interrupt handler function pointer type definition */
	typedef void (*InterruptHandlerPtr_TypeDef)(void);
	/* The Vector Table */
	__attribute__((used, section(".isr_vector")))
	InterruptHandlerPtr_TypeDef g_pfnVectors[] = {
	/* Initial stack pointer */
	(InterruptHandlerPtr_TypeDef)(uintptr_t)_estack,
	/* Core exceptions */
	#if defined(STM32F10X_LD)
	Reset_Handler,
	NMI_Handler,
	HardFault_Handler,
	MemManage_Handler,
	BusFault_Handler,
	UsageFault_Handler,
	NULL,
	NULL,
	NULL,
	NULL,
	SVC_Handler,
	DebugMon_Handler,
	NULL,
	PendSV_Handler,
	SysTick_Handler,
	/* External interrupts */
	WWDG_IRQHandler,
	PVD_IRQHandler,
	TAMPER_IRQHandler,
	RTC_IRQHandler,
	FLASH_IRQHandler,
	RCC_IRQHandler,
	EXTI0_IRQHandler,
	EXTI1_IRQHandler,
	EXTI2_IRQHandler,
	EXTI3_IRQHandler,
	EXTI4_IRQHandler,
	DMA1_Channel1_IRQHandler,
	DMA1_Channel2_IRQHandler,
	DMA1_Channel3_IRQHandler,
	DMA1_Channel4_IRQHandler,
	DMA1_Channel5_IRQHandler,
	DMA1_Channel6_IRQHandler,
	DMA1_Channel7_IRQHandler,
	ADC1_2_IRQHandler,
	USB_HP_CAN1_TX_IRQHandler,
	USB_LP_CAN1_RX0_IRQHandler,
	CAN1_RX1_IRQHandler,
	CAN1_SCE_IRQHandler,
	EXTI9_5_IRQHandler,
	TIM1_BRK_IRQHandler,
	TIM1_UP_IRQHandler,
	TIM1_TRG_COM_IRQHandler,
	TIM1_CC_IRQHandler,
	TIM2_IRQHandler,
	TIM3_IRQHandler,
	NULL,
	I2C1_EV_IRQHandler,
	I2C1_ER_IRQHandler,
	NULL,
	NULL,
	SPI1_IRQHandler,
	NULL,
	USART1_IRQHandler,
	USART2_IRQHandler,
	NULL,
	EXTI15_10_IRQHandler,
	RTCAlarm_IRQHandler,
	USBWakeUp_IRQHandler,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	#elif defined(STM32F10X_LD_VL)
	(InterruptHandlerPtr_TypeDef)(uintptr_t)_estack,
	Reset_Handler,
	NMI_Handler,
	HardFault_Handler,
	MemManage_Handler,
	BusFault_Handler,
	UsageFault_Handler,
	NULL,
	NULL,
	NULL,
	NULL,
	SVC_Handler,
	DebugMon_Handler,
	NULL,
	PendSV_Handler,
	SysTick_Handler,
	WWDG_IRQHandler,
	PVD_IRQHandler,
	TAMPER_IRQHandler,
	RTC_IRQHandler,
	FLASH_IRQHandler,
	RCC_IRQHandler,
	EXTI0_IRQHandler,
	EXTI1_IRQHandler,
	EXTI2_IRQHandler,
	EXTI3_IRQHandler,
	EXTI4_IRQHandler,
	DMA1_Channel1_IRQHandler,
	DMA1_Channel2_IRQHandler,
	DMA1_Channel3_IRQHandler,
	DMA1_Channel4_IRQHandler,
	DMA1_Channel5_IRQHandler,
	DMA1_Channel6_IRQHandler,
	DMA1_Channel7_IRQHandler,
	ADC1_IRQHandler,
	NULL,
	NULL,
	NULL,
	NULL,
	EXTI9_5_IRQHandler,
	TIM1_BRK_TIM15_IRQHandler,
	TIM1_UP_TIM16_IRQHandler,
	TIM1_TRG_COM_TIM17_IRQHandler,
	TIM1_CC_IRQHandler,
	TIM2_IRQHandler,
	TIM3_IRQHandler,
	NULL,
	I2C1_EV_IRQHandler,
	I2C1_ER_IRQHandler,
	NULL,
	NULL,
	SPI1_IRQHandler,
	NULL,
	USART1_IRQHandler,
	USART2_IRQHandler,
	NULL,
	EXTI15_10_IRQHandler,
	RTCAlarm_IRQHandler,
	CEC_IRQHandler,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	TIM6_DAC_IRQHandler,
	TIM7_IRQHandler,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	#elif defined(STM32F10X_MD)
	Reset_Handler,
	NMI_Handler,
	HardFault_Handler,
	MemManage_Handler,
	BusFault_Handler,
	UsageFault_Handler,
	NULL,
	NULL,
	NULL,
	NULL,
	SVC_Handler,
	DebugMon_Handler,
	NULL,
	PendSV_Handler,
	SysTick_Handler,
	/* External interrupts */
	WWDG_IRQHandler,
	PVD_IRQHandler,
	TAMPER_IRQHandler,
	RTC_IRQHandler,
	FLASH_IRQHandler,
	RCC_IRQHandler,
	EXTI0_IRQHandler,
	EXTI1_IRQHandler,
	EXTI2_IRQHandler,
	EXTI3_IRQHandler,
	EXTI4_IRQHandler,
	DMA1_Channel1_IRQHandler,
	DMA1_Channel2_IRQHandler,
	DMA1_Channel3_IRQHandler,
	DMA1_Channel4_IRQHandler,
	DMA1_Channel5_IRQHandler,
	DMA1_Channel6_IRQHandler,
	DMA1_Channel7_IRQHandler,
	ADC1_2_IRQHandler,
	USB_HP_CAN1_TX_IRQHandler,
	USB_LP_CAN1_RX0_IRQHandler,
	CAN1_RX1_IRQHandler,
	CAN1_SCE_IRQHandler,
	EXTI9_5_IRQHandler,
	TIM1_BRK_IRQHandler,
	TIM1_UP_IRQHandler,
	TIM1_TRG_COM_IRQHandler,
	TIM1_CC_IRQHandler,
	TIM2_IRQHandler,
	TIM3_IRQHandler,
	TIM4_IRQHandler,
	I2C1_EV_IRQHandler,
	I2C1_ER_IRQHandler,
	I2C2_EV_IRQHandler,
	I2C2_ER_IRQHandler,
	SPI1_IRQHandler,
	SPI2_IRQHandler,
	USART1_IRQHandler,
	USART2_IRQHandler,
	USART3_IRQHandler,
	EXTI15_10_IRQHandler,
	RTCAlarm_IRQHandler,
	USBWakeUp_IRQHandler,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	#elif defined(STM32F10X_MD_VL)
	Reset_Handler,
	NMI_Handler,
	HardFault_Handler,
	MemManage_Handler,
	BusFault_Handler,
	UsageFault_Handler,
	NULL,
	NULL,
	NULL,
	NULL,
	SVC_Handler,
	DebugMon_Handler,
	NULL,
	PendSV_Handler,
	SysTick_Handler,
	/* External interrupts */
	WWDG_IRQHandler,
	PVD_IRQHandler,
	TAMPER_IRQHandler,
	RTC_IRQHandler,
	FLASH_IRQHandler,
	RCC_IRQHandler,
	EXTI0_IRQHandler,
	EXTI1_IRQHandler,
	EXTI2_IRQHandler,
	EXTI3_IRQHandler,
	EXTI4_IRQHandler,
	DMA1_Channel1_IRQHandler,
	DMA1_Channel2_IRQHandler,
	DMA1_Channel3_IRQHandler,
	DMA1_Channel4_IRQHandler,
	DMA1_Channel5_IRQHandler,
	DMA1_Channel6_IRQHandler,
	DMA1_Channel7_IRQHandler,
	ADC1_IRQHandler,
	NULL,
	NULL,
	NULL,
	NULL,
	EXTI9_5_IRQHandler,
	TIM1_BRK_TIM15_IRQHandler,
	TIM1_UP_TIM16_IRQHandler,
	TIM1_TRG_COM_TIM17_IRQHandler,
	TIM1_CC_IRQHandler,
	TIM2_IRQHandler,
	TIM3_IRQHandler,
	TIM4_IRQHandler,
	I2C1_EV_IRQHandler,
	I2C1_ER_IRQHandler,
	I2C2_EV_IRQHandler,
	I2C2_ER_IRQHandler,
	SPI1_IRQHandler,
	SPI2_IRQHandler,
	USART1_IRQHandler,
	USART2_IRQHandler,
	USART3_IRQHandler,
	EXTI15_10_IRQHandler,
	RTCAlarm_IRQHandler,
	CEC_IRQHandler,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	TIM6_DAC_IRQHandler,
	TIM7_IRQHandler,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	#elif defined(STM32F10X_HD)
	Reset_Handler,
	NMI_Handler,
	HardFault_Handler,
	MemManage_Handler,
	BusFault_Handler,
	UsageFault_Handler,
	NULL,
	NULL,
	NULL,
	NULL,
	SVC_Handler,
	DebugMon_Handler,
	NULL,
	PendSV_Handler,
	SysTick_Handler,
	/* External interrupts */
	WWDG_IRQHandler,
	PVD_IRQHandler,
	TAMPER_IRQHandler,
	RTC_IRQHandler,
	FLASH_IRQHandler,
	RCC_IRQHandler,
	EXTI0_IRQHandler,
	EXTI1_IRQHandler,
	EXTI2_IRQHandler,
	EXTI3_IRQHandler,
	EXTI4_IRQHandler,
	DMA1_Channel1_IRQHandler,
	DMA1_Channel2_IRQHandler,
	DMA1_Channel3_IRQHandler,
	DMA1_Channel4_IRQHandler,
	DMA1_Channel5_IRQHandler,
	DMA1_Channel6_IRQHandler,
	DMA1_Channel7_IRQHandler,
	ADC1_2_IRQHandler,
	USB_HP_CAN1_TX_IRQHandler,
	USB_LP_CAN1_RX0_IRQHandler,
	CAN1_RX1_IRQHandler,
	CAN1_SCE_IRQHandler,
	EXTI9_5_IRQHandler,
	TIM1_BRK_IRQHandler,
	TIM1_UP_IRQHandler,
	TIM1_TRG_COM_IRQHandler,
	TIM1_CC_IRQHandler,
	TIM2_IRQHandler,
	TIM3_IRQHandler,
	TIM4_IRQHandler,
	I2C1_EV_IRQHandler,
	I2C1_ER_IRQHandler,
	I2C2_EV_IRQHandler,
	I2C2_ER_IRQHandler,
	SPI1_IRQHandler,
	SPI2_IRQHandler,
	USART1_IRQHandler,
	USART2_IRQHandler,
	USART3_IRQHandler,
	EXTI15_10_IRQHandler,
	RTCAlarm_IRQHandler,
	USBWakeUp_IRQHandler,
	TIM8_BRK_IRQHandler,
	TIM8_UP_IRQHandler,
	TIM8_TRG_COM_IRQHandler,
	TIM8_CC_IRQHandler,
	ADC3_IRQHandler,
	FSMC_IRQHandler,
	SDIO_IRQHandler,
	TIM5_IRQHandler,
	SPI3_IRQHandler,
	UART4_IRQHandler,
	UART5_IRQHandler,
	TIM6_IRQHandler,
	TIM7_IRQHandler,
	DMA2_Channel1_IRQHandler,
	DMA2_Channel2_IRQHandler,
	DMA2_Channel3_IRQHandler,
	DMA2_Channel4_5_IRQHandler,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	#elif defined(STM32F10X_HD_VL)
	Reset_Handler,
	NMI_Handler,
	HardFault_Handler,
	MemManage_Handler,
	BusFault_Handler,
	UsageFault_Handler,
	NULL,
	NULL,
	NULL,
	NULL,
	SVC_Handler,
	DebugMon_Handler,
	NULL,
	PendSV_Handler,
	SysTick_Handler,
	/* External interrupts */
	WWDG_IRQHandler,
	PVD_IRQHandler,
	TAMPER_IRQHandler,
	RTC_IRQHandler,
	FLASH_IRQHandler,
	RCC_IRQHandler,
	EXTI0_IRQHandler,
	EXTI1_IRQHandler,
	EXTI2_IRQHandler,
	EXTI3_IRQHandler,
	EXTI4_IRQHandler,
	DMA1_Channel1_IRQHandler,
	DMA1_Channel2_IRQHandler,
	DMA1_Channel3_IRQHandler,
	DMA1_Channel4_IRQHandler,
	DMA1_Channel5_IRQHandler,
	DMA1_Channel6_IRQHandler,
	DMA1_Channel7_IRQHandler,
	ADC1_IRQHandler,
	NULL,
	NULL,
	NULL,
	NULL,
	EXTI9_5_IRQHandler,
	TIM1_BRK_TIM15_IRQHandler,
	TIM1_UP_TIM16_IRQHandler,
	TIM1_TRG_COM_TIM17_IRQHandler,
	TIM1_CC_IRQHandler,
	TIM2_IRQHandler,
	TIM3_IRQHandler,
	TIM4_IRQHandler,
	I2C1_EV_IRQHandler,
	I2C1_ER_IRQHandler,
	I2C2_EV_IRQHandler,
	I2C2_ER_IRQHandler,
	SPI1_IRQHandler,
	SPI2_IRQHandler,
	USART1_IRQHandler,
	USART2_IRQHandler,
	USART3_IRQHandler,
	EXTI15_10_IRQHandler,
	RTCAlarm_IRQHandler,
	CEC_IRQHandler,
	TIM12_IRQHandler,
	TIM13_IRQHandler,
	TIM14_IRQHandler,
	NULL,
	NULL,
	NULL,
	NULL,
	TIM5_IRQHandler,
	SPI3_IRQHandler,
	UART4_IRQHandler,
	UART5_IRQHandler,
	TIM6_DAC_IRQHandler,
	TIM7_IRQHandler,
	DMA2_Channel1_IRQHandler,
	DMA2_Channel2_IRQHandler,
	DMA2_Channel3_IRQHandler,
	DMA2_Channel4_5_IRQHandler,
	DMA2_Channel5_IRQHandler,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	#elif defined(STM32F10X_XL)
	Reset_Handler, /* Reset handler */
	NMI_Handler, /* Non Maskable Interrupt handler */
	HardFault_Handler, /* Hard Fault handler */
	MemManage_Handler, /* Memory Management Fault handler */
	BusFault_Handler, /* Bus Fault handler */
	UsageFault_Handler, /* Usage Fault handler */
	NULL, /* Reserved */
	NULL, /* Reserved */
	NULL, /* Reserved */
	NULL, /* Reserved */
	SVC_Handler, /* SVCall handler */
	DebugMon_Handler, /* Debug Monitor handler */
	NULL, /* Reserved */
	PendSV_Handler, /* PendSV handler */
	SysTick_Handler, /* SysTick handler */
	/* External interrupts */
	WWDG_IRQHandler,
	PVD_IRQHandler,
	TAMPER_IRQHandler,
	RTC_IRQHandler,
	FLASH_IRQHandler,
	RCC_IRQHandler,
	EXTI0_IRQHandler,
	EXTI1_IRQHandler,
	EXTI2_IRQHandler,
	EXTI3_IRQHandler,
	EXTI4_IRQHandler,
	DMA1_Channel1_IRQHandler,
	DMA1_Channel2_IRQHandler,
	DMA1_Channel3_IRQHandler,
	DMA1_Channel4_IRQHandler,
	DMA1_Channel5_IRQHandler,
	DMA1_Channel6_IRQHandler,
	DMA1_Channel7_IRQHandler,
	ADC1_2_IRQHandler,
	USB_HP_CAN1_TX_IRQHandler,
	USB_LP_CAN1_RX0_IRQHandler,
	CAN1_RX1_IRQHandler,
	CAN1_SCE_IRQHandler,
	EXTI9_5_IRQHandler,
	TIM1_BRK_TIM9_IRQHandler,
	TIM1_UP_TIM10_IRQHandler,
	TIM1_TRG_COM_TIM11_IRQHandler,
	TIM1_CC_IRQHandler,
	TIM2_IRQHandler,
	TIM3_IRQHandler,
	TIM4_IRQHandler,
	I2C1_EV_IRQHandler,
	I2C1_ER_IRQHandler,
	I2C2_EV_IRQHandler,
	I2C2_ER_IRQHandler,
	SPI1_IRQHandler,
	SPI2_IRQHandler,
	USART1_IRQHandler,
	USART2_IRQHandler,
	USART3_IRQHandler,
	EXTI15_10_IRQHandler,
	RTCAlarm_IRQHandler,
	USBWakeUp_IRQHandler,
	TIM8_BRK_TIM12_IRQHandler,
	TIM8_UP_TIM13_IRQHandler,
	TIM8_TRG_COM_TIM14_IRQHandler,
	TIM8_CC_IRQHandler,
	ADC3_IRQHandler,
	FSMC_IRQHandler,
	SDIO_IRQHandler,
	TIM5_IRQHandler,
	SPI3_IRQHandler,
	UART4_IRQHandler,
	UART5_IRQHandler,
	TIM6_IRQHandler,
	TIM7_IRQHandler,
	DMA2_Channel1_IRQHandler,
	DMA2_Channel2_IRQHandler,
	DMA2_Channel3_IRQHandler,
	DMA2_Channel4_5_IRQHandler,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	#elif defined(STM32F10X_CL)
	Reset_Handler,
	NMI_Handler,
	HardFault_Handler,
	MemManage_Handler,
	BusFault_Handler,
	UsageFault_Handler,
	NULL,
	NULL,
	NULL,
	NULL,
	SVC_Handler,
	DebugMon_Handler,
	NULL,
	PendSV_Handler,
	SysTick_Handler,
	/* External interrupts */
	WWDG_IRQHandler,
	PVD_IRQHandler,
	TAMPER_IRQHandler,
	RTC_IRQHandler,
	FLASH_IRQHandler,
	RCC_IRQHandler,
	EXTI0_IRQHandler,
	EXTI1_IRQHandler,
	EXTI2_IRQHandler,
	EXTI3_IRQHandler,
	EXTI4_IRQHandler,
	DMA1_Channel1_IRQHandler,
	DMA1_Channel2_IRQHandler,
	DMA1_Channel3_IRQHandler,
	DMA1_Channel4_IRQHandler,
	DMA1_Channel5_IRQHandler,
	DMA1_Channel6_IRQHandler,
	DMA1_Channel7_IRQHandler,
	ADC1_2_IRQHandler,
	CAN1_TX_IRQHandler,
	CAN1_RX0_IRQHandler,
	CAN1_RX1_IRQHandler,
	CAN1_SCE_IRQHandler,
	EXTI9_5_IRQHandler,
	TIM1_BRK_IRQHandler,
	TIM1_UP_IRQHandler,
	TIM1_TRG_COM_IRQHandler,
	TIM1_CC_IRQHandler,
	TIM2_IRQHandler,
	TIM3_IRQHandler,
	TIM4_IRQHandler,
	I2C1_EV_IRQHandler,
	I2C1_ER_IRQHandler,
	I2C2_EV_IRQHandler,
	I2C2_ER_IRQHandler,
	SPI1_IRQHandler,
	SPI2_IRQHandler,
	USART1_IRQHandler,
	USART2_IRQHandler,
	USART3_IRQHandler,
	EXTI15_10_IRQHandler,
	RTCAlarm_IRQHandler,
	OTG_FS_WKUP_IRQHandler,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	TIM5_IRQHandler,
	SPI3_IRQHandler,
	UART4_IRQHandler,
	UART5_IRQHandler,
	TIM6_IRQHandler,
	TIM7_IRQHandler,
	DMA2_Channel1_IRQHandler,
	DMA2_Channel2_IRQHandler,
	DMA2_Channel3_IRQHandler,
	DMA2_Channel4_IRQHandler,
	DMA2_Channel5_IRQHandler,
	ETH_IRQHandler,
	ETH_WKUP_IRQHandler,
	CAN2_TX_IRQHandler,
	CAN2_RX0_IRQHandler,
	CAN2_RX1_IRQHandler,
	CAN2_SCE_IRQHandler,
	OTG_FS_IRQHandler,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	#endif
	(InterruptHandlerPtr_TypeDef)BootRAM,
	};
	/**
	* @brief An infinite loop function.
	*
	*/
	__attribute__((noreturn)) static void Infinite_Loop(void)
	{
	while (1) {
	/* Infinite loop */
	}
	}
	/**
	* @brief The default interrupt handler.
	*
	* @param None
	* @return None
	*
	* @note This function is called when an interrupt is triggered that is not handled by any other interrupt handler.
	*/
	void Default_Handler(void)
	{
	Infinite_Loop();
	}
	/**
	* @brief Copy the data segment initializers from flash to SRAM
	* @param None
	* @retval None
	*/
	static void CopyDataInit(void)
	{
	volatile const uint32_t *src_begin = (void *)_sidata;
	const uint32_t *data_end = (void *)_edata;
	volatile uint32_t *data_begin = (void *)_sdata;
	while (data_begin < data_end) {
	*data_begin = *src_begin;
	data_begin++;
	src_begin++;
	}
	}
	/**
	* @brief Zero fill the bss segment
	* @param None
	* @retval None
	*/
	static void FillZerobss(void)
	{
	volatile uint32_t *bss_begin = (void *)_sbss;
	const uint32_t *bss_end = (void *)_ebss;
	while (bss_begin < bss_end) {
	*bss_begin = 0x00;
	bss_begin++;
	}
	}
	/**
	* @brief This is the code that gets called when the processor first
	* starts execution following a reset event. Only the absolutely
	* necessary set is performed, after which the application
	* supplied main() routine is called.
	* @param None
	* @retval None
	*/
	__attribute__((noreturn)) void Reset_Handler(void)
	{
	/* Copy the data segment initializers from flash to SRAM */
	CopyDataInit();
	/* Zero fill the bss segment */
	FillZerobss();
	/* Call the clock system initialization function */
	SystemInit();
	/* Call static constructors */
	__libc_init_array();
	/* Call the application's entry point */
	main();
	/* Should never reach here */
	Infinite_Loop();
	}
